RAYZR TWP

DIODE LASER

Rayzr - TWP

Rayzr – TWP is called Diode Laser. An absolute pain-free treatment for those who want to get rid of their body hair. Having Sapphire Crystal cooling tip, the product has a German-made diode source that works in a user-friendly way. Its efficient Japanese cooling system and water flow sensor is quick to finish the process within a shorter period of time. Moreover, it’s best for Fitzpatrick skin types from I to VI. This product can be installed easily. Due to its lightweight, it can be plugged and operated efficiently. learn more

Get Brochure

Maximum Working Temperature

85℃ with no environment limit Can operate continuously for up to 100 days
Additional Features No need for deionized water, filters, or consumables No risk of laser burning.

Product Offer

Includes three different types of handles
Silicone Small Tip Also Available
Handles available in spot sizes:
14*14mm and 14*23mm

Key Features

•	Absolute pain-free treatment with focused wavelength (810nm)
•	Highly efficient latest advanced cooling technology (2 TEC Cooling System, SLD, and Water)
•	Shorter treatment time with higher repetition rate & large spot size.
•	Long life span with more than 50 million shots.
•	Main spare parts imported from Germany, South Korea and USA
•	24 hours non-stop working
•	Best for Fitzpatrick skin types I to VI
•	User-friendly interface & easy to operate
•	Plug & Play
•	Easy to move due to its lightweight

Technical Specifications

Model	RAYZR-TWP
OUTPUT POWER OF LASER	600W/800W/1200/1800/2400/3200
TRIPLE WAVELENGTH	755nm, 810nm, 980nm, 1064nm
COOLING SYSTEM	2 TEC Cooling System +Air + Water
PROBE TEMPERATURE	-5 degree Celcius to 0 deg Celcius
LED SCREEN	9.7″ Touch Screen (V)
Spot Size	14x14mm2 / 14*23 mm2
INTENSITY WITH FEQ	10-100J/cm2
ENERGY	40J/cm2
PULSE DURATION	5-500ms
FREQUENCY	1-10Hz
VOLTAGE	220v 50Hz/110v 60Hz
Warranty	2.5 Year
